Thiết bị đo tốc độ vòng quay PCE-LES 100

LED Handtachometer - PCE-LES 100
LED Handtachometer / light and compact / 60 ... 99.990 flash/min range /
one handed operation with 6 keys / 2 very bright LEDS (370 lux 50 cm) /
duplication and division of impulses / tripod conection

The PCE-LES 100 LED Handtachometer combines LED technology with a compact and accurate electronics, which controls the sequence and timing of flash over the entire measuring range. Thanks to LED technology, the LED Handtachometer does not need to periodically change the bulbs. The LED Handtachometer is ideal for non-contact revolutions measurements and to visualize movements on machinery and equipment, getting the viewer the impression that the object is stationary. The LED Handtachometer can be used in a wide variety of jobs, in which it is important to make visible very fast movements (eg vibration) due to its wide frequency range and the different lengths of flash. Thanks to the compact design of the LED Handtachometer and the possibility of keeping it your pocket or shirt, you can always have it with you. The PCE-LES 100 LED Handtachometer is powered by two standard batteries (AA) included in the shipment. For more models of a Stroboscope, go to our main page of Handtachometers.

PCE.LES 100 LED held Handtachometer

- Handheld stroboscope with LED technology (no  need to change light bulbs)

Technical Specifications

Range

60 ... 99.990 r.p.m

1 ... 1.666 Hz

Display

5 digits LCD

Impulses / Flash

possibility of duplication and division / fine tuning

Offset

yes, 360 º

Accuracy

60 ... 17.300 17.300 ... 99.990

0

±1 LSD
±0,009 %

Light source

LED

Light intensity

370 lux (50 cm distance, 6.000 r.p.m.)

Battery

2 x AA batteries

Operating time

11h

Environmental conditions

-10 ... 50 ºC

Dimensions

124 x 71 x 33 mm

Weight

173 g

Uses of the PCE-LES 100 LED Handtachometer

Delivery content

1 x PCE-LES 100 LED Handtachometer
2 X AA batteries
1 x carrying case,
user´s manual.
